Example of using the REST API to create an entry on a form - Documentation for AR System 21.05

This example provides information to get multiple entries in a Simple form.

Request URL

GET

Request headers

Authorization: AR-JWT eyJhbGciOiJIUzI1NiJ9.
eyJleHAiOjE0MTc2NTM1ODgsInN1YiI6IkFsbGVuIiwibm
JmIjoxNDE3NjQ5ODY4LCJpc3MiOiJXLUNTRUlFUk9FLTI5Lm
FkcHJvZC5ibWMuY29tIiwianRpIjoiSURHQUFCRFVDMllHSUFONkJGUTJBQUFFUEZBNVFXIiwiX
2NhY2hlSWQiOjQ3LCJpYXQiOjE0MTc2NDk5ODh9.V4LGLcEdwD8V_I4rzoWYYSZmEMA82LBB_lEfz4Xnz9Y

This example provides information about the Rest API request parameters to get multiple entries.

Request URL

 host:8008/api/arsys/v2.0/entry/SampleForm/?q=('Status'="Assigned")&sort=Real
Number Field.asc&offset=1&limit=2&fields=values(Request ID,Real
Number Field)

Request headers

Authorization: AR-JWT eyJhbGciOiJIUzI1NiJ9.
eyJleHAiOjE0MTc2NTM1ODgsInN1YiI6IkFsbGVuIiwibm
JmIjoxNDE3NjQ5ODY4LCJpc3MiOiJXLUNTRUlFUk9FLTI5Lm
FkcHJvZC5ibWMuY29tIiwianRpIjoiSURHQUFCRFVDMllHSUFONkJGUTJBQUFFUEZBNVFXIiwiX
2NhY2hlSWQiOjQ3LCJpYXQiOjE0MTc2NDk5ODh9.V4LGLcEdwD8V_I4rzoWYYSZmEMA82LBB_lEfz4Xnz9Y

Response body

[{ "values": { "Request ID": "000000000000004", "Real Number Field": 3245.215566 }, "_links": { "self": [{ "href": " host:8008/api/arsys/v1/entry/QueryParamTest/000000000000004" }] }
}, { "values": { "Request ID": "000000000000001", "Real Number Field": 223232.213266 }, "_links": { "self": [{ "href": " host:8008/api/arsys/v1/entry/QueryParamTest/000000000000001" }] }
}]

Following is a sample code snippet for the POST operation for multiple entries.

package com.example;
import java.nio.charset.StandardCharsets;
import org.apache.http.HttpEntity;
import org.apache.http.client.methods.CloseableHttpResponse;
import org.apache.http.client.methods.HttpGet;
import org.apache.http.impl.client.CloseableHttpClient;
import org.apache.http.impl.client.HttpClients;
import org.apache.http.util.EntityUtils;
public class GetMultiple { public static void main(String[] args) throws Exception { String token = args[0]; // start HTTP GET to get an entry CloseableHttpClient httpClient = HttpClients.createDefault(); HttpGet httpGet = new HttpGet(""); // add the token to the header httpGet.addHeader("Authorization", "AR-JWT " + token); // make the call and print the status try (CloseableHttpResponse response = httpClient.execute(httpGet)) { HttpEntity entity = response.getEntity(); String jsonEntry = EntityUtils.toString(entity, StandardCharsets.UTF_8); System.out.println(jsonEntry); } }
}

This example provides information to create an entry with an attachment in a Simple form.

Request URL

 host:8008/api/arsys/v2.0/entry/SampleForm/?q=('Status'="Assigned")&sort=Real
Number Field.asc&offset=1&limit=2&fields=values(Request ID,Real
Number Field)

Request headers

Authorization: AR-JWT eyJhbGciOiJIUzI1NiJ9.
eyJzdWIiOiJxSmNGRjgwY0JOeTgyUDRkUm1vTz
RHZ1dKQ1QrZ3pzYUpybVwvMFRwMktMYkJXeUd4ZWt1VG1VMW1r
NXkzcE9aRk9NRlhVM1JTZ3BDbjRNUmR4MVRQRnpGQ2hpNE5KaGk3ZUxCNVlFOFFz
VVJuYm1HbklHaVc0UT09IiwibmJmIjoxNDQ3NzkzMjQ5LCJfaW1wZXJzb25hdGVkVXNl
ciI6bnVsbCwiaXNzIjoiVy1DU0VJRVJPRS0yOS5hZHByb2QuYm1jLmNvbSIsIl9jYWNoZUlkIjox
NDAsImV4cCI6MTQ0Nzc5Njk2OSwiaWF0IjoxNDQ3NzkzMzY5LCJqdGkiOiJJREdBQUJEVUMyWU
dJQU5YWkk4N0FBQkJPV0RORTkifQ.S4PqNJ_LNLqHxfbI6nn7lJA_aI4_-qDVx4hqR3TfprQ
Content-Length: 17553
Content-Type: multipart/form-data;boundary=W3NByNRZZYy4ALu6xeZzvWXU3NVmYUxoRB

Request body

--W3NByNRZZYy4ALu6xeZzvWXU3NVmYUxoRB
Content-Disposition: form-data; name="entry"
Content-Type: application/json; charset=UTF-8
Content-Transfer-Encoding: 8bit
{	"values" :	{ "Submitter" :"Allen", "Short Description" : "testing 123", "Attachment1" : "sample.jpg"	}
}
--W3NByNRZZYy4ALu6xeZzvWXU3NVmYUxoRB
Content-Disposition: form-data;
name="attach-Attachment1"; filename="sample.png"
Content-Type: application/octet-stream
Content-Transfer-Encoding: binary
<binary data removed for brevity>
--W3NByNRZZYy4ALu6xeZzvWXU3NVmYUxoRB--

Response body

HTTP/1.1 200 OK
Date: Wed, 03 Dec 2014 22:53:46 GMT
Content-Type: application/json
Server: Jetty(8.1.15.v20140411)
{
"entries": [	{ "values":	{ "Request ID":"000000000000103","Submitter":"Allen", "Create Date":"2014-12-03T22:53:37.000+0000", "Assigned To":null, "Last Modified By":"chris", "Modified Date":"2014-12-03T22:53:37.000+0000", "Status":"New", "Short Description":"testing 123", "Status History":{	"New":{	"user":"chris",	"timestamp":"2014-12-03T22:53:37.000+0000" }	}	},	"_links":{	"self":[	{"href":"" } ] } } ], "_links":{	"self":[ {"href":"" } ] }
}

This example provides information to retrieve records from record 200 to record 400 in a form.

Request URL

 host:8008/api/arsys/v2.0/entry/SampleForm?offset=200&limit=200

Request headers

Authorization: AR-JWT eyJhbGciOiJIUzI1NiJ9.
eyJleHAiOjE0MTc2NTM1ODgsInN1YiI6IkFsbGVuIiwibm
JmIjoxNDE3NjQ5ODY4LCJpc3MiOiJXLUNTRUlFUk9FLTI5Lm
FkcHJvZC5ibWMuY29tIiwianRpIjoiSURHQUFCRFVDMllHSUFONkJGUTJBQUFFUEZBNVFXIiwiX
2NhY2hlSWQiOjQ3LCJpYXQiOjE0MTc2NDk5ODh9.V4LGLcEdwD8V_I4rzoWYYSZmEMA82LBB_lEfz4Xnz9Y

Response body

{ "entries": [ { "values": { "Request ID": "000000000000201", "Character Field1": null, "Submitter": "SG1U4", "Character Field2": null, "Create Date": "2017-01-13T08:49:49.000+0000", "Status History": { "New": { "user": "Demo", "timestamp": "2017-01-13T08:49:49.000+0000" } }, "Character Field14": null, "Notifier Listening": "Not Listening", "Character Field15": null, "112": "30000;30001;30002;30003;30004;30005;30006;30007;30008;30009;30010;30011;30012;30013;30014;30015;30016;30017;30018;30019;30020;30021;30022;30023;30024;30025;30026;30027;30028;30029;30030;30031;30032;30033;30034;30035;30036;30037;30038;30039;30040;30041;30042;30043;30044;30045;30046;30047;30048;30049;", "Record ID": "AGGIZW4ECUGASAQPD9ZIQPD9ZI02O8" }, "_links": { "self": [ { "href": "" } ] } }, { "values": { "Request ID": "000000000000202", "Character Field1": null, "Submitter": "SG1U4", "Status History": { "New": { "user": "Demo", "timestamp": "2017-01-13T08:49:49.000+0000" } }, "Character Field14": null, "Notifier Listening": "Not Listening", "Character Field15": null, "112": "30000;30001;30002;30003;30004;30005;30006;30007;30008;30009;30010;30011;30012;30013;30014;30015;30016;30017;30018;30019;30020;30021;30022;30023;30024;30025;30026;30027;30028;30029;30030;30031;30032;30033;30034;30035;30036;30037;30038;30039;30040;30041;30042;30043;30044;30045;30046;30047;30048;30049;", "Record ID": "AGGIZW4ECUGASAQPD9ZIQPD9ZI02O9" }, "Record ID": "AGGIZW4ECUGASAQPD9ZIQPD9ZI02UB" }, "_links": { "self": [ { "href": "" } ] } },
…
…
… { "values": { "Request ID": "000000000000400", "Character Field1": null, "Submitter": "SG1U8", "Status History": { "New": { "user": "Demo", "timestamp": "2017-01-13T08:49:50.000+0000" } }, "Character Field14": null, "Notifier Listening": "Not Listening", "Character Field15": null, "112": "30000;30001;30002;30003;30004;30005;30006;30007;30008;30009;30010;30011;30012;30013;30014;30015;30016;30017;30018;30019;30020;30021;30022;30023;30024;30025;30026;30027;30028;30029;30030;30031;30032;30033;30034;30035;30036;30037;30038;30039;30040;30041;30042;30043;30044;30045;30046;30047;30048;30049;", "Record ID": "AGGIZW4ECUGASAQPD9ZIQPD9ZI02UC" }, "_links": { "self": [ { "href": "" } ] } } ], "_links": { "next": [ { "href": "" } ], "prev": [ { "href": "" } ], "self": [ { "href": "" } ] }
}
