Network ports - Documentation for BMC TrueSight Operations Management 11.3.04

ComponentProtocolDefault port numberFunction

App Visibility portal

App Visibility portalHTTPS8100

Communication to an App Visibility portal from the following components:

• App Visibility collectors
• App Visibilityproxies
• App Visibilityagents for Java and .NET
• TEA Agents

• TrueSight Presentation Server

App Visibility portal supportabilityHTTPS8101Communication to an App Visibility portal supportability console by BMC Customer Support, accessed via a browserApp Visibility portal node synchronization portHTTPS5701Communication with the paired portal node for HAApp Visibility portal databaseHTTPS8800

Communication to the database from the App Visibility portal

Communication is local; you do not need to open a firewall for external communication.

App Visibility collector

App Visibility collectorHTTPS8200

Communication to an App Visibility collector from the following components:

• App Visibility portal
• App Visibility proxy
• App Visibility agents for Java and .NET
• TEA Agents

App Visibility collector supportabilityHTTPS8201

Communication to an App Visibility collector supportability console by BMC Customer Support, accessed via a browser

App Visibility collector node synchronization portHTTPS5702Communication with the paired collector node for HAApp Visibility collector databaseHTTPS8800

Communication to the database from the App Visibility collector

Communication is local; you do not need to open a firewall for external communication.

App Visibility proxy

App Visibility proxyHTTPS8300Communication to an App Visibility proxy from an App Visibility portal
App Visibility proxy supportabilityHTTPS8301Communication to an App Visibility proxy for supportabilityBeacon receiver, HTTPHTTP8304For HTTP pages, receives beacons from the end-user's browsersBeacon receiver, HTTPSHTTPS8305For HTTPS pages, receives beacons from the end-user's browsersStorage HTTPHTTP8302

Communication to the storage engine from the App Visibility proxy

Communication is local; you do not need to open a firewall for external communication.

Storage TCPTCP8303

Communication between App Visibility proxy storage engine nodes in a cluster

Communication between the nodes is secured using SSL/TLS.

App Visibility agent for Java

App Visibility agent for Java supportabilityHTTPS50000-50100 Communication to an App Visibility agent for Java supportability console by BMC Customer Support, accessed via a browser

App Visibility agent for .NET

App Visibility agent for .NETNot applicableNot applicableNot applicable

Synthetic TEA Agent

Synthetic Transaction Execution Adapter (TEA) AgentNot applicableNot applicableNot applicable
