Configuring A10 Networks load balancers - Documentation for BMC Cloud Lifecycle Management 4.6

 Click here to view the sample node blueprint for the A10 Loadbalancer host.

<nodeBlueprint xsi:type="containerLoadBalancerHostBlueprint" xmlns:xsi="">

            <addressBlueprints/>

            <category>7</category>

          <dummyHostFlag>false</dummyHostFlag>

            <name>A10 Load Balancer - Standalone</name>

            <numVrfs>0</numVrfs>

            <role>ActiveLoadBalancer</role>

            <virtualGuestBlueprint xsi:type="containerVlbBlueprint">

                <configureActionInfoBlueprints>

                <configureActionInfoBlueprint xsi:type="customActionInfoBlueprint">

                    <name>Create Partition</name>

                    <guid>5A52453D-F481-484F-90FD-AC5B80644B50</guid>

                    <runtimeProps>

                        <item>

                            <key>partitionName</key>

                            <value>${container.node.guestDevice.name}</value>

                        </item>

                        <item>

                            <key>partitionId</key>

                            <value>${container.integers[PartitionId]}</value>

                        </item>

                    </runtimeProps>

                </configureActionInfoBlueprint>

            </configureActionInfoBlueprints>

                <useHostAddressForGuest>true</useHostAddressForGuest>

                <guestDeviceName>${container.name}-VLB</guestDeviceName>

                <useExistingGuestDeviceFlag>false</useExistingGuestDeviceFlag>

                <guestNodeName>VLB</guestNodeName>

                <sharesVirtualDevice>false</sharesVirtualDevice>

                <unconfigureActionInfoBlueprints>

                <unconfigureActionInfoBlueprint xsi:type="customActionInfoBlueprint">

                    <name>Create Partition</name>

                    <guid>59DB17E7-7DD7-4A3F-B182-A2AA48F12746</guid>

                    <runtimeProps>

                        <item>

                            <key>partitionName</key>

                            <value>${container.node.guestDevice.name}</value>

                        </item>

                        <item>

                            <key>partitionId</key>

                            <value>${container.integers[PartitionId]}</value>

                        </item>

                    </runtimeProps>

                </unconfigureActionInfoBlueprint>

            </unconfigureActionInfoBlueprints>

                <addEntryGuid>75BABC33-3574-44DD-9426-2AB40744B53B</addEntryGuid>

                <addPoolGuid>78B5336D-E153-48C4-B639-66E1A20CAB3A</addPoolGuid>

                <defaultEnabledFlag>true</defaultEnabledFlag>

                <disableEntryGuid>14E30858-2FCE-4319-8DF3-BEAE9971B059</disableEntryGuid>

                <enableEntryGuid>F7CEFDAB-0B4A-493B-B4CF-05386C27F6D2</enableEntryGuid>

                <lockedFlag>false</lockedFlag>

                <poolTypeBlueprints>

                    <poolTypeBlueprint>

                        <name>Customer Network 1</name>

                        <serverVlanName>C_VLAN1</serverVlanName>

                        <servicedNicSegmentNames>

                            <servicedNicSegmentName>Customer Network 1</servicedNicSegmentName>

                        </servicedNicSegmentNames>

                        <snatBlockSize>2</snatBlockSize>

                        <snatPoolName>C_VLAN1</snatPoolName>

                        <vipSegmentName>VIPS Customer Network 1</vipSegmentName>

                    </poolTypeBlueprint>

                </poolTypeBlueprints>

                <removeEntryGuid>3C9AB2B6-0F2E-4C09-BB1E-2FC44FD9E0AC</removeEntryGuid>

                <removePoolGuid>329A51DA-684D-439E-BDF5-DCE42302BC29</removePoolGuid>

            </virtualGuestBlueprint>

        </nodeBlueprint>
