Configuration variables that are for internal use only - Documentation for BMC PATROL for Oracle Database Monitoring 9.7
Configuration variable
Description
/AgentSetup/ORACLE_ CATEGORY. ORACLE_SID.defaultAccount
specifies a default username and password combination for the application class (ORACLE_ CATEGORY ) in its name
/AgentSetup/ ORACLE_DATAGUARD_INSTANCE. hostName: standbyInstanceName.defaultAccount
stores the sys user password of the configured standby instance The hostName variable indicates the name of the host where the standby instance is running.
/AgentSetup/ ORACLE_DATAGUARD_DATABASE. primaryInstanceName.defaultAccount
stores the PATROL database user password of the configured primary instance in Oracle KM
/AgentSetup/ORACLE_SQLVIEWER. ORACLE_SID.collectorRunning
indicates whether the collector for SQL Viewer is running.
/AgentSetup/ORACLE_SQLVIEWER. ORACLE_SID.collStartTime
start time of the SQLViewer collector
/AgentSetup/ORACLE_SQLVIEWER. ORACLE_SID.collStopTime
stop time of the SQLViewer collector
/AgentSetup/ORACLE.temp. defaultAccount
temporary default account
/DGConfig. standbyInstanceName.monDGInstType
stores the type of standby, it can be physical or logical
/DGConfig. standbyInstanceName.TNSService
indicates the TNS entry of a standby instance
/DGConfig.monDGDBList
stores the list of configured database names of the primary instances
/DGConfig. primaryDatabaseName.monDGInstList
stores the names of the standby instances configured for a primary database
/DGConfig. primaryInstanceName.DBHome
ORACLE HOME of primary instance
/DGConfig. primaryInstanceName.DBName
stores the database name of primary instance This pconfig gets created only when primary instance is configured with auto db configuration in ORACLE.kml.
/ORACLE_AVAILABILITY. ORACLE_SID.ArchFreeSpace.active
indicates whether the ArchFreeSpace parameter was deactivated by the KM
/ORACLE_AVAILABILITY.sid. tempTSparams.deactivatedByKM
indicates whether the TempTSLeftPct and TempTSLeft parameters were deactivated by the KM
/ORACLE_AVAILABILITY. ORACLE_SID.tempOSTableExists
indicates that the p$temp_os_space table exists, that the collector need not create this table, and that the collector can count on the presence of this table
/ORACLE_AVAILABILITY. ORACLE_SID.temp.TableExists
indicates that the p$temp_ts_space table exists, that the collector need not create the table, and that the collector can count on the presence of this table
/ORACLE_AVAILABILITY. ORACLE_SID.FreeSpace.kmactive
indicates whether the FreeSpace parameter was deactivated by the KM
/ORACLE_AVAILABILITY. ORACLE_SID. FreeSpaceDeficit.kmactive
indicates whether the FreeSpaceDeficit parameter was deactivated by the KM
/ORACLE_INSTANCE. ORACLE_SID. localInstance
indicates whether an instance is monitored locally or remotely
/OracleConfig.FailoverMonitoring. Listener. ORACLE_LISTENER.Active
indicates whether the named listener is a part of the Failover Configuration
/OracleConfig. ORACLE_SID. AlertFileInfo_eof_pos
indicates the end of the file for the alert log
/OracleConfig. ORACLE_SID. AlertFileInfo_modtime
last time the alert log was modified
/OracleConfig. ORACLE_SID. AlertFileInfo_size
size of the Alert Log
/OracleConfig. ORACLE_SID. ALTERNEXT. SCHEMA NAME. OBJECT NAME
indicates whether the KM is set to alter the next extent of the object in the schema if there is a space problem.
/OracleConfig. ORACLE_SID. ARCHIVELOG.DIRECTORY
directory where archive log is moved when the current archive destination is full
/OracleConfig. ORACLE_SID. ConfigTime
time of last configuration or reconfiguration activity for the ORACLE_SID instance
/OracleConfig. ORACLE_SID. DBAUsername
username of the dba account used to configure the KM for ORACLE_SID
/OracleConfig. ORACLE_SID.DBName
name of the database
/OracleConfig. ORACLE_SID. dbObjectsDeinstalled
indicates whether the database objects have been deinstalled
/OracleConfig. ORACLE_SID >. FailoverMonitoring.AlternateListenerName
alternate listener for failover monitoring
/OracleConfig. ORACLE_SID.Failover Monitoring.LocalFailoverListenerName
local listener name for failover monitoring
/OracleConfig. ORACLE_SID.Name
name of database; identical to SID
/OracleConfig. ORACLE_SID.NumPrivs
number of privileges granted to patrol user
/OracleConfig. ORACLE_SID. RECOVERY
indicates whether recovery is set
/OracleConfig. ORACLE_SID. RECOVERY.ARCHIVELOG
indicates which action PATROL for Oracle performs when the archive log destination is full: compress (compress log files), or MOVE (create new destination for log file)
/OracleConfig.ObjectsList
list of database objects (tables, views, synonyms) created by instance configuration
/OracleConfig.PackageBodyList
list of package bodies created by instance configuration
/OracleConfig.PackageList
list of packages created by instance configuration
/OracleConfig.SessTimeStamp
time of completion of last activity for session settings
/OracleConfig.TimeStamp
time of completion of last activity for instance configuration
/OracleConfig.UsrTimeStamp
time of completion of last activity for User settings
