Cluster node - Documentation for BMC Helix Discovery
UI Name
Relationship
Description
Activity Records
ActedUpon:
Activity:
ActivityRecord:
ActivityRecord
Record of model activity associated with this Cluster
Administrative Collections
Member:
Collection:
Collection:
AdminCollection
Administrative Collections this Cluster is a member of
Collections
Member:
Collection:
Collection:
Collection
Collections this Cluster is a member of
Deployments
Member:
Collection:
Collection:
Deployment
Deployments this Cluster is a member of
Subnets
Member:
Collection:
Collection:
Subnet
Subnets this Cluster is a member of
Namespace
Member:
Collection:
Collection:
Namespace
Namespace this Cluster is in
Deployments
Collection:
Collection:
Member:
Deployment
Deployments that are members of this Cluster
Namespaces
Collection:
Collection:
Member:
Namespace
Namespaces defined in this Cluster
Software Pods
Collection:
Collection:
Member:
SoftwarePod
Software Pods that are members of this Cluster
Clusters
Container:
Containment:
Contained:
Cluster
Clusters contained in this Cluster
Cluster
Contained:
Containment:
Container:
Cluster
Containing Cluster
Cluster Members
Container:
Containment:
Contained:
ClusterMember
Cluster Members contained in this Cluster
Load Balancer Services
Container:
Containment:
ContainedService:
LoadBalancerService
Load Balancer Services contained in this Cluster
Clusters This Depends On
Dependant:
Dependency:
DependedUpon:
Cluster
Clusters that this Cluster depends on
Clusters Depending Upon This
DependedUpon:
Dependency:
Dependant:
Cluster
Clusters that depend on this Cluster
Databases This Depends On
Dependant:
Dependency:
DependedUpon:
Database
Databases that this Cluster depends on
Database Details This Depends On
Dependant:
Dependency:
DependedUpon:
DatabaseDetail
Database Details that this Cluster depends on
Details This Depends On
Dependant:
Dependency:
DependedUpon:
Detail
Details that this Cluster depends on
Files This Depends On
Dependant:
Dependency:
DependedUpon:
File
Files that this Cluster depends on
Runtime Environments This Depends On
Dependant:
Dependency:
DependedUpon:
RuntimeEnvironment
Runtime Environments that this Cluster depends on
Software Clusters This Depends On
Dependant:
Dependency:
DependedUpon:
SoftwareCluster
Software Clusters that this Cluster depends on
Software Components This Depends On
Dependant:
Dependency:
DependedUpon:
SoftwareComponent
Software Components that this Cluster depends on
Software Instances This Depends On
Dependant:
Dependency:
DependedUpon:
SoftwareInstance
Software Instances that this Cluster depends on
Software Pods This Depends On
Dependant:
Dependency:
DependedUpon:
SoftwarePod
Software Pods that this Cluster depends on
Virtual Machines This Depends On
Dependant:
Dependency:
DependedUpon:
VirtualMachine
Virtual Machines that this Cluster depends on
Databases Depending Upon This
DependedUpon:
Dependency:
Dependant:
Database
Databases that depend on this Cluster
Details Depending Upon This
DependedUpon:
Dependency:
Dependant:
Detail
Details that depend on this Cluster
Software Clusters Depending Upon This
DependedUpon:
Dependency:
Dependant:
SoftwareCluster
Software Clusters that depend on this Cluster
Software Components Depending Upon This
DependedUpon:
Dependency:
Dependant:
SoftwareComponent
Software Components that depend on this Cluster
Software Containers Depending Upon This
DependedUpon:
Dependency:
Dependant:
SoftwareContainer
Software Containers that depend on this Cluster
Software Instances Depending Upon This
DependedUpon:
Dependency:
Dependant:
SoftwareInstance
Software Instances that depend on this Cluster
Software Pods Depending Upon This
DependedUpon:
Dependency:
Dependant:
SoftwarePod
Software Pods that depend on this Cluster
Virtual Machines Depending Upon This
DependedUpon:
Dependency:
Dependant:
VirtualMachine
Virtual Machines that depend on this Cluster
Category
ElementInCategory:
ElementCategory:
Category:
Category
Category
Member Hosts
HostContainer:
HostContainment:
ContainedHost:
Host
Hosts that are part of this Cluster
Member Network Devices
HostContainer:
HostContainment:
ContainedHost:
NetworkDevice
Network Devices that are part of this Cluster
Member Virtual Machines
HostContainer:
HostContainment:
ContainedHost:
VirtualMachine
Virtual Machines that are part of this Cluster
Member MF Parts
HostContainer:
HostContainment:
ContainedHost:
MFPart
MF Parts that are part of this Sysplex
Member Coupling Facilities
HostContainer:
HostContainment:
CouplingFacility:
CouplingFacility
Coupling Facilities that are part of this Sysplex
Managed Services
ServiceHost:
HostedService:
RunningService:
ClusterService
Services managed by this Cluster
Candidate Software Instances
Host:
HostedSoftware:
RunningSoftware:
CandidateSoftwareInstance
Candidate Software Instances running on this Cluster
External Elements
Host:
HostedSoftware:
RunningSoftware:
ExternalElement
External Elements running on this Cluster
Runtime Environments
Host:
HostedSoftware:
RunningSoftware:
RuntimeEnvironment
Runtime Environments running on this Cluster
Software Containers
Host:
HostedSoftware:
RunningSoftware:
SoftwareContainer
Software Containers running on this Cluster
Software Instances
Host:
HostedSoftware:
RunningSoftware:
SoftwareInstance
Software Instances running on this Cluster
Software Pods
Host:
HostedSoftware:
RunningSoftware:
SoftwarePod
Software Pods running on this Cluster
Unassigned Connections
Host:
HostedSoftware:
RunningSoftware:
UnassignedConnections
Unassigned Connections running on this Cluster
Virtual Machines
Host:
HostedSoftware:
RunningSoftware:
VirtualMachine
Virtual Machines running on this Cluster
Primary Business Application
InferredElement:
Inference:
Primary:
BusinessApplicationInstance
Business Application from which the existence of this Cluster was inferred
Primary Business Service
InferredElement:
Inference:
Primary:
BusinessService
Business Service from which the existence of this Cluster was inferred
Primary Technical Service
InferredElement:
Inference:
Primary:
TechnicalService
Technical Service from which the existence of this Cluster was inferred
Primary Device Info
InferredElement:
Inference:
Primary:
DeviceInfo
Device Info from which the existence of this Cluster was inferred
Primary Discovered Application Component
InferredElement:
Inference:
Primary:
DiscoveredApplicationComponent
Discovered Application Component from which the existence of this Cluster was inferred
Primary Discovered Cloud API Result List
InferredElement:
Inference:
Primary:
DiscoveredCloudAPIResultList
Discovered Cloud API Result List from which the existence of this Cluster was inferred
Primary Discovered Coupling Facility
InferredElement:
Inference:
Primary:
DiscoveredCouplingFacility
Discovered Coupling Facility from which the existence of this Cluster was inferred
Primary Discovered Database
InferredElement:
Inference:
Primary:
DiscoveredDatabase
Discovered Database from which the existence of this Cluster was inferred
Primary Discovered Database Detail
InferredElement:
Inference:
Primary:
DiscoveredDatabaseDetail
Discovered Database Detail from which the existence of this Cluster was inferred
Primary Discovered Directory Entry
InferredElement:
Inference:
Primary:
DiscoveredDirectoryEntry
Discovered Directory Entry from which the existence of this Cluster was inferred
Primary Discovered Disk Drive
InferredElement:
Inference:
Primary:
DiscoveredDiskDrive
Discovered Disk Drive from which the existence of this Cluster was inferred
Primary Discovered File
InferredElement:
Inference:
Primary:
DiscoveredFile
Discovered File from which the existence of this Cluster was inferred
Primary Discovered File System
InferredElement:
Inference:
Primary:
DiscoveredFileSystem
Discovered File System from which the existence of this Cluster was inferred
Primary Discovered HBA
InferredElement:
Inference:
Primary:
DiscoveredHBA
Discovered HBA from which the existence of this Cluster was inferred
Primary Discovered IP Address
InferredElement:
Inference:
Primary:
DiscoveredIPAddress
Discovered IP Address from which the existence of this Cluster was inferred
Primary Listening Port
InferredElement:
Inference:
Primary:
DiscoveredListeningPort
Listening Port from which the existence of this Cluster was inferred
Primary Discovered MFPart
InferredElement:
Inference:
Primary:
DiscoveredMFPart
Discovered MFPart from which the existence of this Cluster was inferred
Primary Discovered MQ Detail
InferredElement:
Inference:
Primary:
DiscoveredMQDetail
Discovered MQ Detail from which the existence of this Cluster was inferred
Primary Discovered Mainframe
InferredElement:
Inference:
Primary:
DiscoveredMainframe
Discovered Mainframe from which the existence of this Cluster was inferred
Primary Discovered Mainframe View Result
InferredElement:
Inference:
Primary:
DiscoveredMainframeViewResult
Discovered Mainframe View Result from which the existence of this Cluster was inferred
Primary Discovered Network Interface
InferredElement:
Inference:
Primary:
DiscoveredNetworkInterface
Discovered Network Interface from which the existence of this Cluster was inferred
Primary Discovered Process
InferredElement:
Inference:
Primary:
DiscoveredProcess
Discovered Process from which the existence of this Cluster was inferred
Primary Discovered Program
InferredElement:
Inference:
Primary:
DiscoveredProgram
Discovered Program from which the existence of this Cluster was inferred
Primary Discovered Registry Entry
InferredElement:
Inference:
Primary:
DiscoveredRegistryEntry
Discovered Registry Entry from which the existence of this Cluster was inferred
Primary Discovered Service
InferredElement:
Inference:
Primary:
DiscoveredService
Discovered Service from which the existence of this Cluster was inferred
Primary Discovered Software
InferredElement:
Inference:
Primary:
DiscoveredSoftware
Discovered Software from which the existence of this Cluster was inferred
Primary Discovered Storage Subsystem
InferredElement:
Inference:
Primary:
DiscoveredStorageSubsystem
Discovered Storage Subsystem from which the existence of this Cluster was inferred
Primary Discovered Sysplex
InferredElement:
Inference:
Primary:
DiscoveredSysplex
Discovered Sysplex from which the existence of this Cluster was inferred
Primary Discovered Tape Drive
InferredElement:
Inference:
Primary:
DiscoveredTapeDrive
Discovered Tape Drive from which the existence of this Cluster was inferred
Primary Discovered Transaction
InferredElement:
Inference:
Primary:
DiscoveredTransaction
Discovered Transaction from which the existence of this Cluster was inferred
Primary Discovered Virtual Machine
InferredElement:
Inference:
Primary:
DiscoveredVirtualMachine
Discovered Virtual Machine from which the existence of this Cluster was inferred
Primary Host Info
InferredElement:
Inference:
Primary:
HostInfo
Host Info from which the existence of this Cluster was inferred
Primary MF Part
InferredElement:
Inference:
Primary:
MFPart
MF Part from which the existence of this Cluster was inferred
Primary Network Connection List
InferredElement:
Inference:
Primary:
NetworkConnectionList
Network Connection List from which the existence of this Cluster was inferred
Primary Software Component
InferredElement:
Inference:
Primary:
SoftwareComponent
Software Component from which the existence of this Cluster was inferred
Primary Software Container
InferredElement:
Inference:
Primary:
SoftwareContainer
Software Container from which the existence of this Cluster was inferred
Primary Software Instance
InferredElement:
Inference:
Primary:
SoftwareInstance
Software Instance from which the existence of this Cluster was inferred
Location
ElementInLocation:
Location:
Location:
Location
Location of this Cluster
Maintaining Pattern
Element:
Maintainer:
Pattern:
Pattern
Pattern maintaining this Cluster
Managed by Cluster
ManagedElement:
Management:
Manager:
Cluster
Cluster that manages this Cluster
Managed Clusters
Manager:
Management:
ManagedElement:
Cluster
Clusters that this Cluster manages
Managed by Software Cluster
ManagedElement:
Management:
Manager:
SoftwareCluster
Software Cluster that manages this Cluster
Managed by Software Instance
ManagedElement:
Management:
Manager:
SoftwareInstance
Software Instance that manages this Cluster
Managed by Network Device
ManagedElement:
Management:
Manager:
NetworkDevice
Network Device that manages this Cluster
Managed Collections
Manager:
Management:
ManagedElement:
Collection
Collections that this Cluster manages
Managed Administrative Collections
Manager:
Management:
ManagedElement:
AdminCollection
Administrative Collections that this Cluster manages
Business Owner
OwnedItem:
Ownership:
BusinessOwner:
Person
The person or owner responsible for this element from a business perspective
IT Owner
OwnedItem:
Ownership:
ITOwner:
Person
The person or owner responsible for this element from an IT perspective
Support Manager
OwnedItem:
Ownership:
SupportOwner:
Person
The person or owner responsible for the support of this element
Owner
OwnedItem:
Ownership:
Owner:
Person
The owner of this element
Cloud Service
Service:
SoftwareService:
ServiceProvider:
CloudService
Cloud Service that provides this logical cluster
Service Software Cluster
Service:
SoftwareService:
ServiceProvider:
SoftwareCluster
Software Clusters that provide this logical cluster
Service Software
Service:
SoftwareService:
ServiceProvider:
SoftwareInstance
Software Instances that provide this logical cluster
Attachments
AttachmentContainer:
Attachment:
Attachment:
Attachment
A file attached to this element
Category
ElementInCategory:
ElementCategory:
Category:
Category
Category
Family
ElementInCategory:
ElementCategory:
Category:
Family
Family
Lifecycle Status
ElementInCategory:
ElementCategory:
Category:
LifecycleStatus
Lifecycle Status
Recovery Time
ElementInCategory:
ElementCategory:
Category:
RecoveryTime
Recovery Time
Location
ElementInLocation:
Location:
Location:
Location
Location of this Managed Element
Business Owner
OwnedItem:
Ownership:
BusinessOwner:
Person
The person or owner responsible for this element from a business perspective
IT Owner
OwnedItem:
Ownership:
ITOwner:
Person
The person or owner responsible for this element from an IT perspective
Support Manager
OwnedItem:
Ownership:
SupportOwner:
Person
The person or owner responsible for the support of this element
Owner
OwnedItem:
Ownership:
Owner:
Person
The owner of this element
Organizational Unit
OwnedItem:
Ownership:
Owner:
OrganisationalUnit
Organizational Unit that this Managed Element belongs to
